编译安装Nginx

系统版本

1
2
# cat /etc/system-release
CentOS Linux release 7.6.1810 (Core)

编译安装Nginx 1.20.1

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61
62
63
64
65
66
67
68
69
70
71
72
73
74
75
76
77
78
79
80
81
82
83
84
85
86
87
88
89
90
91
92
93
94
95
96
97
98
99
100
101
#!/bin/bash
# Close selinux
setenforce 0 &> /dev/null

# Install the compilation environment in advance
yum install -y wget gcc gcc-c++ pcre pcre-devel openssl openssl-devel zlib zlib-devel gd gd-devel

# Download nginx source code package
#--->>> Only modify the following parameters <<<---

nginx_version=1.20.1
nginx_prefix_dir=/usr/local/nginx
install_package_dir=/usr/local/src
install_log_dir="./install_nginx.log"

#--->>> Only modify the above parameters <<<---

cd ${install_package_dir} && \
ls ./${nginx_version}.tar.gz || wget http://nginx.org/download/nginx-${nginx_version}.tar.gz &&\
tar xf ./${nginx_version}.tar.gz -C ${install_package_dir} && cd ./nginx-${nginx_version} && \
useradd -s /sbin/nologin nginx

# Compile and install
./configure --prefix=${nginx_prefix_dir} \
--user=nginx \
--group=nginx \
--with-pcre \
--with-http_ssl_module \
--with-http_v2_module \
--with-http_realip_module \
--with-http_addition_module \
--with-http_sub_module \
--with-http_dav_module \
--with-http_flv_module \
--with-http_mp4_module \
--with-http_gunzip_module \
--with-http_gzip_static_module \
--with-http_random_index_module \
--with-http_secure_link_module \
--with-http_stub_status_module \
--with-http_auth_request_module \
--with-http_image_filter_module \
--with-http_slice_module \
--with-mail \
--with-threads \
--with-file-aio \
--with-stream \
--with-mail_ssl_module \
--with-stream_ssl_module

if [[ $? -ne 0 ]];then
    echo "Compilation failed. Please check!";exit 2
fi
make && make install

# Configure nginx daemons
cat >/usr/lib/systemd/system/nginx.service <<EOF
[Unit]
Description=nginx - high performance web server
Documentation=https://nginx.org/en/docs/
After=network.target remote-fs.target nss-lookup.target

[Service]
Type=forking
PIDFile=${nginx_prefix_dir}/logs/nginx.pid
ExecStartPre=${nginx_prefix_dir}/sbin/nginx -t -c ${nginx_prefix_dir}/conf/nginx.conf
ExecStart=${nginx_prefix_dir}/sbin/nginx -c ${nginx_prefix_dir}/conf/nginx.conf
ExecReload=${nginx_prefix_dir}/sbin/nginx -s reload
ExecStop=${nginx_prefix_dir}/sbin/nginx -s stop
PrivateTmp=true

[Install]
WantedBy=multi-user.target
EOF
chmod +x /usr/lib/systemd/system/nginx.service
systemctl daemon-reload

# Set Nginx to boot automatically
systemctl enable nginx --now
# systemctl restart nginx && systemctl enable nginx

# Add to PATH
# Add Soft Connection
ln -s ${nginx_prefix_dir}/sbin/nginx /usr/sbin/nginx

# Add environment variables
#cat >/etc/profile.d/nginx.sh<<EOF
#export NGINX_HOME=${nginx_prefix_dir}
#export PATH=\$PATH:\$NGINX_HOME/sbin
#EOF
#source /etc/profile

# Print installation information
cat > ${install_log_dir} <<EOF
[Info]
Binary: ln -s ${nginx_prefix_dir}/sbin/nginx /usr/sbin/nginx
Daemon: /usr/lib/systemd/system/nginx.service
[Detail]
EOF
nginx -V &>> ./${install_log_dir}
clear; cat ./${install_log_dir}

Nginx添加模块

基于编译安装方式的Nginx新增模块、版本升级

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
# 查看nginx路径
rpm -ql nginx | grep sbin
# 查看当前Nginx已安装模块，记录configure argument:
# nginx -V
nginx version: nginx/1.20.1
built by gcc 4.8.5 20150623 (Red Hat 4.8.5-44) (GCC)
built with OpenSSL 1.0.2k-fips  26 Jan 2017
TLS SNI support enabled
configure arguments: --prefix=/usr/local/nginx --user=nginx --group=nginx --with-pcre --with-http_ssl_module --with-http_v2_module --with-http_realip_module --with-http_addition_module --with-http_sub_module --with-http_dav_module --with-http_flv_module --with-http_mp4_module --with-http_gunzip_module --with-http_gzip_static_module --with-http_random_index_module --with-http_secure_link_module --with-http_stub_status_module --with-http_auth_request_module --with-http_image_filter_module --with-http_slice_module --with-mail --with-threads --with-file-aio --with-stream --with-mail_ssl_module --with-stream_ssl_module

# 编译安装Nginx依赖
yum -y install gcc gcc-c++ make libtool zlib zlib-devel openssl openssl-devel pcre pcre-devel
cd /usr/local/src
wget http://nginx.org/download/nginx-1.20.1.tar.gz
tar xf nginx-1.20.1.tar.gz
cd nginx-1.20.1

查看需要开启的内置模块

添加内置模块

./configure + 已编译参数 + 新增模块

1
2
3
4
5
6
7
8
9
10
# 查看nginx内置模块
./configure --help | grep xxx_module

# 重新编译nginx
./configure \
# 旧二进制 configure arguments \
--with-xxx_module   // 根据./configure --help中查看的方式添加

# 禁止make install，否则会覆盖现有的nginx
make

添加第三方模块

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
# 下载第三方模块
wget http://xxx.tgz

# 复制模块到指定目录
cp xxx_module /usr/local/src/nginx-1.20.1/xxx_module

# 重新编译
cd /usr/local/src/nginx-1.20.1
./configure \
--prefix=/usr/local/nginx \
--user=nginx \
--group=nginx \
--with-pcre \
--with-http_ssl_module \
--with-http_v2_module \
--with-http_realip_module \
--with-http_addition_module \
--with-http_sub_module \
--with-http_dav_module \
--with-http_flv_module \
--with-http_mp4_module \
--with-http_gunzip_module \
--with-http_gzip_static_module \
--with-http_random_index_module \
--with-http_secure_link_module \
--with-http_stub_status_module \
--with-http_auth_request_module \
--with-http_image_filter_module \
--with-http_slice_module \
--with-mail \
--with-threads \
--with-file-aio \
--with-stream \
--with-mail_ssl_module \
--with-stream_ssl_module \
--add-module=/usr/local/src/nginx-1.20.1/xxx_module

# 禁止make install，否则会覆盖现有的nginx
make

# 查看模块是否开启/添加
/usr/local/src/nginx-1.18.0/objs/nginx -V

Nginx平滑升级

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
# 备份当前Nginx二进制文件
cp -a /usr/local/nginx/sbin/nginx{,.bak`date +%Y%m%d`}

# 记录旧 nginx master进程号
ps -ef | grep nginx
ng_master_pid_old=$(ps -ef | grep nginx | awk '/master process/{print $2}')

# 覆盖旧二进制文件
mv /usr/local/src/nginx-1.18.0/objs/nginx /usr/local/nginx/sbin/nginx

# 记录新 nginx master进程号
ps -ef | grep nginx
ng_master_pid_new=$(ps -ef | grep nginx | awk '/master process/{print $2}')

# 挂起老进程
kill -USR2 ng_master_pid_old
# 保存老master进程
kill -WINCH ng_master_pid_old
# 验证无误后升级完成

# 回滚方式
kill -HUP  ng_master_pid_old    //重新拉起老master进程的子进程
kill -QUIT ng_master_pid_new    //优雅退出新master进程
mv /usr/local/nginx/sbin/nginx.bak /usr/local/nginx/sbin/nginx
回滚完成
